Descriptions
O-Rings are used in static sealing and some dynamic applications. O-Rings are made from materials that are matched to the fluids, temperatures and pressures found in engines and machines. The materials resist wear and extrusion, and provide superior resistance to seal compression set. In addition, certain O-Rings are coated with PTFE to minimize seal twisting and cutting during seal installation. Dimensions of our O-Rings are consistently held to tight tolerances to ensure they fit properly into seal grooves with the necessary seal compression.
Attributes:
- Cross Section Diameter (in): 0.139
- Inside Diameter (in): 0.484
- SAE AS568 Dash Size: -206
- Material: FKM - Fluoroelastomer,FKM (75),FKM,Fluoroelastomer (FKM) Rubber
- Material Description: FKM rubber is capable of service temperatures of -40 to 150C and is resistant to air, fuel (including bio-diesel), lubricants and oils. FKM rubber should not be used in applications that require resistance to water or coolant.
- Notes: Dimensions and material descriptions provided for reference only.
- Polymer: FKM (Fluorocarbon)
- Applications: High temperature applications requiring resistance to air, fuels, lubricants and hydraulic fluids
- Not Compatible With: Amines; Brake fluids; Engine Coolant; Fire Resistant Fluids; Ketones; Steam; Water
- Material Hardness: 75A
- Compatible With: Diester lubricants; Halogenated hydrocarbons (above 100 Deg. C); Highly resistant to compression set; Petroleum fluids; Phosphate ester fluids; Silicone fluids; Some acids
- Dash Size: 206
- Temperature (°F): -40° - 350°
- Seal/O-Ring Type: Standard
Compatible Models
PUMPER
SPT343
UNDERGROUND ART TRUCK
AD55 AD30
GENERATOR
SR4 SR4B SR4BHV
TRUCK ENGINE
3406E C-15 C15
POWER MODULE
PM3456
LOAD HAUL DUMP
R2900G R2900
OFF HIGHWAY TRUCK
796 AC
MOTOR GRADER
18
GEN SET-MILITARY
3608
TRACK-TYPE TRACTOR
D10R
MARINE AUXILIARY
3608
MARINE ENGINE
3516 3512 3508 3616 C18 3612 3412 3406E 3208
WHEEL TRACTOR
631E 637E
VEHICULAR ENGINE
3516 3512
TRACK LOADER
973 943 953
PETROLEUM ENGINE
C15
EJECTOR TRUCK
730
WHEEL LOADER
980 XE 980H 982 XE
ENGINE - MACHINE
C4.4
GEN SET ENGINE
3406E 3508 3412 3616 3608 3606 3412C 3512 3516
ARTICULATED TRUCK
725 730
INDUSTRIAL ENGINE
3512C 3516B 3508 3456 3412 C18 3406E C15 3512 3516
WHEEL SCRAPER
657 657B
TRUCK
793F OEM 794 AC
GAS ENGINE
G3606
