Descriptions
O-Rings are used in static sealing and some dynamic applications. O-Rings are made from materials that are matched to the fluids, temperatures and pressures found in engines and machines. The materials resist wear and extrusion, and provide superior resistance to seal compression set. In addition, certain O-Rings are coated with PTFE to minimize seal twisting and cutting during seal installation. Dimensions of our O-Rings are consistently held to tight tolerances to ensure they fit properly into seal grooves with the necessary seal compression.
Attributes:
- Cross Section Diameter (in): 0.139
- Inside Diameter (in): 3.859
- SAE AS568 Dash Size: -241
- Material: FKM - Fluoroelastomer,FKM (75),FKM,Fluoroelastomer (FKM) Rubber
- Material Description: FKM rubber is capable of service temperatures of -40 to 150C and is resistant to air, fuel (including bio-diesel), lubricants and oils. FKM rubber should not be used in applications that require resistance to water or coolant.
- Notes: Dimensions and material descriptions provided for reference only.
- Polymer: FKM (Fluorocarbon)
- Applications: High temperature applications requiring resistance to air, fuels, lubricants and hydraulic fluids
- Not Compatible With: Amines; Brake fluids; Engine Coolant; Fire Resistant Fluids; Ketones; Steam; Water
- Material Hardness: 75A
- Compatible With: Diester lubricants; Halogenated hydrocarbons (above 100 Deg. C); Highly resistant to compression set; Petroleum fluids; Phosphate ester fluids; Silicone fluids; Some acids
- Dash Size: 241
- Temperature (°F): -40 - 350
- Seal/O-Ring Type: Standard
- Primary Sealing Material: Rubber
Compatible Models
UNDERGROUND ART TRUCK
AE40 AD55 AD30 AE40 II AD45 AD40
TRUCK ENGINE
C9 C-10 C-12 3406E 3406C 3406B C-15 3176 3176B
POWER MODULE
PM3456
INTEGRATED TOOLCARRIER
IT18B IT28B
LOAD HAUL DUMP
R2900G R2900
REMAN ENGINE
3406E
OFF HIGHWAY TRUCK
796 AC 794 AC
WINCH
528
HYDRAULIC SHOVEL
6015
WHEEL SKIDDER
518 528 518C
TRACK-TYPE TRACTOR
D7G D6 D8R D6XE D6 XE D4E D4E SR D11T D6T
MARINE ENGINE
C18 C30 C32 3412E
MINING EXCAVATOR
5230 5130B
WHEEL TRACTOR
613 631E 631C
HYDRAULIC CONTROL
173B
TRACK LOADER
973 953C 943 953
PETROLEUM ENGINE
C15
COLD PLANER
PM-565
LANDFILL COMPACTOR
836
WHEEL LOADER
980 XE 960F 950B/950E 950G II 950B 950E 950G 962G 950F G926 916 936E 924G G916 926 980H 980L 980M 936 926E G936 994K 982 XE 982M 950F II
GEN SET ENGINE
3406E
WHEELED EXCAVATOR
M314 M315 M318 M319 M316 M317 M314-07
INDUSTRIAL ENGINE
3412E 3408E C15
TRUCK
793F OEM 775D 795F XQ 793C 795F AC 789D 69D 773D 794 AC 769D
WHEEL SCRAPER
623F 623E 657 657B
QUARRY TRUCK
771D
GAS ENGINE
G3606
BULLDOZER
8A 8S
